Multitrack Packaging Machine
- Minimum Order Quantity
- 1 Piece
- 550000 INR/Piece
With an aim to fulfill the different packaging requirements of the industries, we are manufacturing and exporting an exclusive range of Multitrack Packaging Machine. Our professionals make use of high-grade mild steel painted with epoxy or powder coating paint and modern machines while manufacturing these machines. This Multitrack Packaging Machine is broadly used for packing liquids, pastes, granules and powders in four side seal pouches made up of heat sealable laminate.
- Equipped with closed loop fault detection system
- Reduces the down time
- Fully automatic
Multitrack packing machine (MT-600) :
- Multitrack Packaging Machine is fully automatic and controlled by PLC (Programmable Logic Control), which can pack various Liquids & Pastes (like Shampoo, Ketch-up, Oil, Cream etc.) Granules (like Tea, etc. ) Powders (like Coffee, Milk Powder etc.) in Four side seal pouches made up of Heat Sealable Laminate.
- The production can be taken at maximum from Two Tracks to Six Tracks depending upon the width of the pouch.
- The machine has Film Unwinding Unit and Web Control System, which maintains the tension, constant feed and web alignment of the film.
- This is an intermittent machine where the film is drawn by Rubber Rollers, governed by Electromagnetic Clutch & Brake systems / Servo System.
- The compatible filling system used for Liquid/ Paste is Spool Valve, for Powder and Granules is Volumetric Cup filler & for Tablets & Capsules it is Bowl Feeder.
- The machine is equipped with a separate detachable electrical control panel. Sealing Jaws temperatures are controlled through PID (Proportional Integrative Derivative) Temperature Controller to maintain the precise temperature of the sealing jaws.
- Sealing Jaws (Vertical) are adjustable for different pouch width and photocell arrangement ensures accurate pouch length.
- The multitrack packing machine is equipped with closed loop fault detection system for detecting the fault and hence, reduces the down time.
- The machine is capable of producing pouches in batches (max. upto 99) with optional attachment like Coding, notching and collating system.
- The basic machine construction is of Mild Steel painted with epoxy / powder coating paint after giving necessary treatment of the material.
- Sealing Jaws are made up of Stainless Steel / Special Grade of High Carbon Steel.
- Internationally reputed brands of pneumatics like solenoid valve, pneumatic cylinders, flow control valves etc. are used.
Multitrack Packaging Machine ( MODEL : UFLEX- MT-600 )
600 MM ( Max. )
Upto 40-60 Pouches / Min. / Track
2% ( Max.),
MAX. DIAMETER OF ROLL
NO. OF TRACKS
2-6 Tracks ( Max.) (Depending upon the width of the pouch)
Main Motor - 3 H.P/ 415V/AC/3 PH./50HZ
ELECTRICAL POWER CONSUMPTION
12KW( MAX.) (The Power Consumption increases with optional attachments )
PID ( Proportional Integral Derivative ) temperature
Consumption = 12 CFM
Volumetric Cup Filling, Spool Valve Filling, Bowl Feeding System
APPLICATIVE FILM (POUCH MATERIAL)
Heat Sealable Laminated Film
