Collar Type Form Fill Seal Machine
- Minimum Order Quantity
- 1 Piece
- 700000 INR/Piece
- Product Type
- form fill and seal machine
- Automatic Grade
- Control System
- PLC Control
- Drive Type
- 440 V Watt (w)
- Digital display and keyboard
- Unsurpassed accuracy and speed
- Wrinkle free pouch formation
Further Details :
Collar Type Form Fill Seal Machine is an intermittent motion machine designed for the efficient packing of several products like Snacks Foods, Wafers, Tea, Sugar, Spices, Detergent, Henna Powder etc.The Collar type form fill seal machine is controlled by programmable logic control and has a man machine interface with a digital display and keyboard, which makes this machine operator friendly. Servo Drives for both laminate pulling through friction belts and sealing jaws, give the machine unsurpassed accuracy and speed of up to 120 pouches / min.
The unwinding system is a motorized one, which keeps on feeding the laminate to the pouch forming tube without much pulling tension to enable the machine to form wrinkle free pouch formation.This can be synchronized with different type of dozing systems like Volumetric cup Filling and Weigh Filling System.This machine is suitable for a wide range of heat sealable film as a packing material such as PET/POLY, PET/MET/POLY, laminates with aluminum foil and heat sealable BOPP etc.
It is a versatile machine and the pouch width can be changed very easily by replacing the forming tube and Collar. This machine has an automatic pouch length change system thru PLC and can be adjusted from 65mm to 270mm. Changing of the pouch length does not require any change parts. All product contact parts are made up of food grade stainless steel SS-304/SS-316.The machine needs 3 phase 440 Volts AC Power supply at 50 Hertz with a maximum power consumption of 5.5 KW.Uflex believes in providing the best quality products available in the market to meet the global need to meet International Quality Standards, such as PLC, Servo Drives etc.
The machine can be provided with various optional attachments (at an extra cost) like Nitrogen Flushing and batch-cutting device.Output and accuracy depends on characteristics and quantity of the product to be packed, consistency in bulk density, consistent level in the hopper, maintaining of RH in packing room if the product is hygroscopic in nature.Since continuous development is a process at FLEX and tailor made solutions are provided to the customers, some of the features shown are subjected to change without prior notice.
Features of automatic collar type form fill seal machine :
- Product to be packed - Tea, Sugar, Spices, Henna, Detergent, Salt, Snacks Food, Wrapped Candies, Cheese Biscuits etc.
- Machine - Collar type Form Fill & Seal machine(MODEL: UFLEX - FFS- CT SD )
- Control - PLC (Programmable Logic Control)
- Temperature Controller - PID type
- Pulling Mechanism - Servo Driven Pulling Belts
- Unwinding System - Motorized
- Sealing System - Servo Driven Heat Sealers
- Roll Width - 400 mm (Max.)180 mm ( Min.)
- Pouch Size - 80mm (Width) x 65mm (Repeat) [ Min. ] 190mm (Width) x 270 mm (Repeat) [ Max.]
- Pouch Type - Centre Seal Pouch
- Filling system - Volumetric Cup Filler / Auger Filler / Weigh Filler
- All Product Contact parts - SS-316 / SS-304
- Power Consumption - 5.5 KW.
- Power Supply - 220V A.C / Single Phase / 50 Hz.
- Net Weight - 1500 Kg. ( Approx.)
- Compressed Air - 6 - 8 CFM @ 4-6 pressure bar
- Speed - up to 120 Pouches / min. (Depending upon the product and quantity to be packed)
- Filling Accuracy - + 2% (Volumetric Cup Filling System & Auger) + 1% (Load Cell Based Weigher)
Output & Accuracy depends on following:
- Filling System
- Characteristics of product to be packed
- Quantity of product to be packed
- Consistency in Bulk density / Viscosity of the product
- Consistent level of product in machine hopper
- Maintaining RH in packing room if the product is hygroscope in nature.
- Dimensions (Door Closed) - L= 2125 mm.,W=1360 mm., H = 2950 mm.
- (Door Open) - L= 2500 mm.,W=3200 mm., H = 2950 mm.
- Payment Terms
- Telegraphic Transfer (T/T), Letter of Credit (L/C), Cash in Advance (CID)
- Supply Ability
- Depends on Product Per Week
- Delivery Time
- 12-16 Week
- Main Export Market(s)
- Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
- Main Domestic Market
- All India
