      Automatic Horizontal Flow Wrap Machine

      Automatic Horizontal Flow Wrap Machine
      Automatic Horizontal Flow Wrap Machine
      Send Inquiry
      Product Code : FWM
      Brand Name : Uflex
      Price And Quantity
      • Minimum Order Quantity
      • 1 Piece
      • Price
      • 3500000 INR/Piece
      Product Description

      Being among the topnotch organizations, we are involved in manufacturing and exporting a sturdily constructed array of Automatic Horizontal Flow Wrap Machine in the worldwide market. Our range is designed and developed in accordance with the global quality standards. This versatile Automatic Horizontal Flow Wrap Machine is ideally used for wrapping cubical, irregular shaped solid products and cylindrical products such as disposable syringe, bottle, soap, cake and pre-filled pouches.

      Key Attributes:

      • Programmable logic control
      • Operator friendly man machine interface
      • Minimum wastage of packing material

      Further Details :

      Horizontal Flow Wrap Machine is a very versatile machine which can wrap cubical, irregular shaped solid products, cylindrical products like Bottle / Soap / Cake /Bearing/ Disposable syringe / Pencil Cells / Ice Cream / Spark Plug /Piston Rings/ pre-filled pouches and Similar Product in pillow pack pouch.The machine is an operator friendly with a speed range of 25 to 125 packs per minute. The machine is controlled by programmable logic control and provided with an operator friendly MMI (man machine interface).

      All the temperature controllers provided in the machine are PID. The machine has a built in high response photo registration,cutting of the film even at high speeds which results in minimum wastage of packing material and high sensitivity to ensure accurate positioning of the product .The machine comes with latest and unique features like pouch length adjustment mechanism for a wide range of roll width,  adjustable forming unit, , which ensure short change over times as well as no change parts.

      The machine can be provided with customized in-feed system in synchronization with the process of manufacturing . This machine can be used to pack the products like disposable syringes,soap, chocolate bars, IV Fluid bottles, auto spare parts, bearing etc.Machine can be provided with an optional attachment like overload clutch, coding unit  etc. (at an extra cost).

      Features of Horizontal Flow Wrap Machine:

      Product to be packed Pharmaceutical / Bakery / Personal Care/ Stationary / Automobile / Electrical & other Products
      Qty. to be packed Single (can be designed according to the requirements)
      Machine
      Automatic Flow Wrap Machine (MODEL : UFLEX  FW - 1001)
      Feeding system Auto Feeder / Manual
      Control PLC (Programmable Logic Control)
      Temperature Controller PID type
      Pouch type  Centre Seal Pillow type
      Pouch Size
      • Length = 60 mm - 240 mm
      • Width = 35 mm - 120 mm
      • Height = 10 mm - 70 mm
      Speed 25 - 125 Pouches / Min.
      Output depends on
      (Dimensions & Shape of product Characteristics of packaging material)
      Power Consumption 5 KW
      Power supply 220 V / AC / Single Phase / 50 Hz
      Optional Feature Coding Device
      Batch Cutting
      Over Load Clutch
      Maximum Roll width 380 mm
      Dimensions
      L = 4200 mm., W = 1500 mm., H = 1700 mm.
      Net Weight 850 Kg. (Approx.)
